Motor supply | 230 Vac (50-60Hz) |
Max absorbed current | 1,8 A |
Maximum thrust | 2300 N |
Opening time | 18” |
Standard stroke | 270 mm |
Max stroke | 325 mm |
Duty cycle | 30% |
Protection level | IP44 |
Operating temperature | -20°C /+50°C |
Lubrication | GREASE |
Leaf max dimension | 3.0 m |
Weight | 8.5 kg |
N. motors per pallet | 50 |
Kit weight | 19.6 kg |
N. kits per pallet | 18 |
