DITEC PWR Swing Gate Motor in Abu Dubai
A COMPLETE RANGE
Ditec PWR is the new range of electromechanical actuators for swing gates in residential, condominium and industrial applications. They are designed and developed to ensure quality and strength, while making installation and maintenance easy.
A complete series made up of: a motor for wings up to 2.5 m (Ditec PWR 25), a motor for wings up to 3.5 m (Ditec PWR 35) and three motors for wings up to 5 m (Ditec PWR 50 series).
Distinctive features
Ditec PWR 25
For wings up to 2.5 m
simply loosen a single screw to remove the plastic cover and access the electrical wire terminals
key-operated manual release
actuator consisting of two robust aluminium die castings which guarantee optimum protection against shearing forces and torsion
Ditec PWR 35
For wings up to 3.5 m
simply loosen a single screw to remove the plastic cover and access the electrical wire terminals
key-operated manual release
actuator consisting of two robust aluminium die castings which guarantee optimum protection against shearing forces and torsion
removable cover to access the screw without removing the actuator from the wing
loading valve to inject EP1 universal grease
notches to adjust magnetic limit switches (optional) during opening and closing and supports for cable stop clamps
Ditec PWR50H: IRREVERSIBLE with limit stops UP TO 450,000 CYCLES
Ditec PWR50HV: IRREVERSIBLE with magnetic limit switches UP TO 450,000 CYCLES
Ditec PWR50HR: REVERSIBLE with limit stops UP TO 600,000 CYCLES
manual release designed to guarantee opening with minimal effort
removable cover for easy access to the screw for adjustment and maintenance
mechanical limit stops already assembled both in opening and closing (magnetic limit switches on PWR50HV)
dustproof brushes to protect the screw
SIMPLIFIED installation
Reduces the time needed to install new motors on the PWR series by 60%!
automation system includes asymmetric mechanical opening and closing stops
one-handed installation: the hexagonal impression makes it easier to attach the actuator to the column
pre-drilled plates for fast installation, with robust bushings for optimum distribution of forces along the front connection pin
installation mounting tool includes a spirit level to perfectly calibrate heights in a single step
THE RIGHT AUTOMATION SYSTEM for all applications
set-up for remote manual release, useful when the automation system cannot be reached during an emergency
magnetic limit switch provision (only on PWR35H) for more accurate speed adjustment
ideal solution for applications which require fast opening and closing
SIMPLE ADJUSTMENT, FAST INSTALLATION
precise adjustment of mechanical limit stops directly on the screw (PWR50H and PWR50HR)
magnetic limit switches already assembled and wired (PWR50HV) slotted mounting plate to quickly and easily weld the bracket
